KKmoon 2.4" TFT Digital Oscilloscope Kit With Power Adapter And BNC Clip Cable Probe Ds0150 Assembled Finished Machine

ETEPON EM001 oscilloscope kit is an assembled finished machine which can be used directly. Unlike DIY oscilloscope kit, you don’t need to do assembly or soldering work before using, which will avoid some problem caused on soldering or assembling process and save your time.. Great Replacement. ✔ Extended both in width and height. ✔ Hand-held. Analog channel is placed on a separated board which contains most user install parts, so the analog and digital circuits can be better separated... Specification. Number of Channel: 1 . Analog Bandwidth: 0 - 200KHz . Sensitivity: 5mV/Div - 20V/Div . Sensitivity error: . Resolution: 12-bit . Maximum Input voltage: 50Vpk . Coupling: DC, AC, GND . Trigger Types: Rising/falling edge . Trigger Position: 1/2 of buffer size fixed . Display: 2.4 inch color TFT LCD with 320 x 240 resolution . Power Supply: 9V DC (8 - 10V acceptable), NOT INCLUDED . Dimension: 115mm X 75mm X 22mm . Weight: 100 gram (not including cables and power supply).. Packing Lists. 1 * Oscilloscope . 1 * BNC-clip cable. 1 * Users Manual.. Kindly Note. The power supply voltage must not exceed 10V. 9v dc power supply should be center positive.. ASSEMBLED FINISHED - ETEPOPN EM001 digital DIY oscilloscope kit with case is an assembled finished machine. It can be used directly to avoid assembling/welding process problems and greatly save your time. It reaches 5mV/div - 20V/div, while the others is only 10mV/div - 5v/div. HAND-HELD - This updated digital oscilloscope can be hand-held, while the others can only be used by placing it on the desktop. WHAT YOU GET - You will get a assembled oscilloscope, BNC-clip cable and a power adapter.
