Youyeetoo L1 4D 3D LiDAR Scanner, 360 Degree, 30 Meters Scanning Radius, ROS SLAM LIDAR Sensor, For AGV Robot Navigation And Obstacle Avoidance (L1RM (30M))

Anti-ambient light Effective resistance to indoor ambient lightand outdoor glare interferenceAchieve stable ranging and high accuracymap building under 100Klux outdoor light. Highly transparent objectdetection (glass) Can detect under complex lighting conditionssuitable for a wider range of applications. *The scanning effect differs under different angles and radar parameters configuration, please refer to the actual. Unitree 4D LiDAR-L1 is a cost-effective, safe, and reliable 4D LiDAR (3D position + 1D grayscale) that can achieve high-speed laser ranging sampling at 21,600 times per second. It can be widely used in robotics, smart cities, smart toys, logistics, and other fields, supporting functions such as mapping, positioning, recognition, obstacle avoidance, environment scanning, and 3D reconstruction. The L1 radar can detect objects as close as 0.05 meters and as far as 30 meters away (90% reflectivity). The L1 has outstanding ultra-wide-angle scanning capabilities, with a field of view (FOV) expanding to 360 ° horizontally and 90 ° vertically, enabling three-dimensional space detection of a hemispherical field of view. The L1's azimuthal scanning frequency is 11Hz, and its vertical scanning frequency is 180Hz, with an effective sampling frequency of 21,600 points/second. Manual download：https://oss-global-cdn.unitree. com/static/f5ca3e9038d44ca29f711f90005a2185.pdf
